Resolution:

0,5 μm

Measuring length:

50,0 mm - 2.200,0 mm

Accuracy:

(5+5L/1.000) μm

Protection class:

Scale: IP65; Interface unit IP30

Cable length:

3 m

Discontinued:

Advice:

SR138 + CH04-**C = GB-ER

Product code

Accuracy: (5+5L/1000) μm; Resolution: 0,5 μm

97928518

GB-5ER

with 3 m cable; ML*: 50 mm

97928519

GB-10ER

with 3 m cable; ML*: 100 mm

97928520

GB-15ER

with 3 m cable; ML*: 150 mm

97928521

GB-20ER

with 3 m cable; ML*: 200 mm

97928522

GB-25ER

with 3 m cable; ML*: 250 mm

97928523

GB-30ER

with 3 m cable; ML*:300 mm

97928524

GB-35ER

with 3 m cable; ML*: 350 mm

97928525

GB-40ER

with 3 m cable; ML*: 400 mm

97928526

GB-45ER

with 3 m cable; ML*: 450 mm

97928527

GB-50ER

with 3 m cable; ML*: 500 mm

97928528

GB-55ER

with 3 m cable; ML*: 550 mm

97928529

GB-60ER

with 3 m cable; ML*: 600 mm

97928530

GB-65ER

with 3 m cable; ML*: 650 mm

97928531

GB-75ER

with 3 m cable; ML*: 750 mm

97928532

GB-85ER

with 3 m cable; ML*: 850 mm

97928533

GB-95ER

with 3 m cable; ML*: 950 mm

97928534

GB-105ER

with 3 m cable; ML*: 1.050 mm

97928535

GB-125ER

with 3 m cable; ML*: 1.250 mm

97928536

GB-140ER

with 3 m cable; ML*: 1.400 mm

97928537

GB-160ER

with 3 m cable; ML*: 1.600 mm

97928538

GB-185ER

with 3 m cable; ML*: 1.850 mm

97928539

GB-205ER

with 3 m cable; ML*: 2.050 mm

97928540

GB-220ER

with 3 m cable; ML*: 2.200 mm

Product code

Accuracy: (5+5L/1000) μm; Resolution: 0,5 μm; Cable outlet right

97948748

GB-5ERRC

with 3 m cable; ML*: 50 mm; Cable outlet right

97948749

GB-10ERRC

with 3 m cable; ML*: 100 mm; Cable outlet right

97948750

GB-15ERRC

with 3 m cable; ML*: 150 mm; Cable outlet right

97948751

GB-20ERRC

with 3 m cable; ML*: 200 mm; Cable outlet right

97948752

GB-25ERRC

with 3 m cable; ML*: 250 mm; Cable outlet right

97948753

GB-30ERRC

with 3 m cable; ML*:300 mm; Cable outlet right

97948754

GB-35ERRC

with 3 m cable; ML*: 350 mm; Cable outlet right

97948755

GB-40ERRC

with 3 m cable; ML*: 400 mm; Cable outlet right

Product code

Accuracy: (5+5L/1000) μm; Resolution: 0,5 μm; with 5 m cable length

97938729

GB-010ERT01

with 5 m cable; ML*: 100 mm

97938730

GB-035ERT01

with 5 m cable; ML*: 350 mm

97938731

GB-045ERT01

with 5 m cable; ML*: 450 mm

97938738

GB-075ERT02

with 5 m cable; ML*: 750 mm

97938732

GB-105ERT03

with 5 m cable; ML*: 1.050 mm

97938733

GB-185ERT01

with 5 m cable; ML*: 1.850 mm

Product code

Accuracy: (5+5L/1000) μm; Resolution: 0,5 μm

97928541

SR138-005R

ML*: 50 mm

97928542

SR138-010R

ML*: 100 mm

97928543

SR138-015R

ML*: 150 mm

97928544

SR138-020R

ML*: 200 mm

97928545

SR138-025R

ML*: 250 mm

97928546

SR138-030R

ML*:300 mm

97928547

SR138-035R

ML*: 350 mm

97928548

SR138-040R

ML*: 400 mm

97928549

SR138-045R

ML*: 450 mm

97928550

SR138-050R

ML*: 500 mm

97928551

SR138-055R

ML*: 550 mm

97928552

SR138-060R

ML*: 600 mm

97928553

SR138-065R

ML*: 650 mm

97928554

SR138-075R

ML*: 750 mm

97928555

SR138-085R

ML*: 850 mm

97928556

SR138-095R

ML*: 950 mm

97928557

SR138-105R

ML*: 1.050 mm

97928558

SR138-125R

ML*: 1.250 mm

97928559

SR138-140R

ML*: 1.400 mm

97928560

SR138-160R

ML*: 1.600 mm

97928561

SR138-185R

ML*: 1.850 mm

97928562

SR138-205R

ML*: 2.050 mm

97928563

SR138-220R

ML*: 2.200 mm

Product code

Cable for SR138R

97958564

CH04-03C

Cable for SR138R (3 m; armored)

97938706

CH04-05CT01

Cable for SR138R (5 m; armored)

97966101

CE10-01C

Extension cable (1 m; armored)

97966102

CE10-03C

Extension cable (3 m; armored)

97966103

CE10-05C

Extension cable (5 m; armored)

97966104

CE10-10C

Extension cable (10 m; armored)

Product code

Type

Description

97930125

SZ51-AB01

(AB/UD; RS422/TLL; configurable)

97928895

CE30

Adaptor cable
